Magnetic resonance imaging (MRI), nuclear magnetic resonance imaging (NMRI), or magnetic resonance tomography (MRT) is a medical imaging technique used in radiology to investigate the anatomy and physiology of the body in both health and disease. MRI scanners use strong magnetic fields and radiowaves to form images of the body. The technique is widely used in hospitals for medical diagnosis, staging of disease and for follow-up without exposure to ionizing radiation.
Introduction[]
MRI has a wide range of applications in medical diagnosis and there are estimated to be over 25,000 scanners in use worldwide. MRI has an impact on diagnosis and treatment in many specialties although the effect on improved health outcomes is uncertain. Since MRI does not use any ionizing radiation its use is recommended in preference to CT when either modality could yield the same information. MRI is in general a safe technique but the number of incidents causing patient harm have risen. Contraindications to MRI include most cochlear implants and cardiac pacemakers, shrapnel and metallic foreign bodies in the orbits. The safety of MRI during the first trimester of pregnancy is uncertain, but it may be preferable to alternative options. The sustained increase in demand for MRI within the healthcare industry has led to concerns about cost effectiveness and overdiagnosis.
Neuroimaging[]
MRI is the investigative tool of choice for neurological cancers as it is more sensitive than CT for small tumors and offers better visualization of the posterior cranial fossa. The contrast provided between grey and white matter makes it the optimal choice for many conditions of the central nervous system including demyelinating diseases, dementia, cerebrovascular disease, infectious diseases, and epilepsy. MRI is also used in MRI-guided stereotactic surgery and radiosurgery for treatment of intracranial tumors, arteriovenous malformations and other surgically treatable conditions.
Cardiovascular[]
Cardiac MRI is complementary to other imaging techniques, such as echocardiography, cardiac CT and nuclear medicine. Its applications include assessment of myocardial ischemia and viability, cardiomyopathies, myocarditis, iron overload, vascular diseases, and congenital heart disease.
Musculoskeletal[]
Applications in the musculoskeletal system include spinal imaging, assessment of joint disease and soft tissue tumors.
Liver and gastrointestinal MRI[]
Hepatobiliary MR is used to detect and characterize lesions of the liver, pancreas, and bile duct. Focal or diffuse disorders of the liver may be evaluated using diffusion-weighted, opposed-phase imaging and dynamic contrast enhancement sequences. Extracellular contrast agents are widely used in liver MRI and newer hepatobiliary contrast agents also provide the opportunity to perform functional biliary imaging. Anatomical imaging of the bile ducts is achieved by using a heavily T2-weighted sequence in magnetic resonance cholangiopancreatography (MRCP). Functional imaging of the pancreas is performed following administration of secretin. MR enterography provides non-invasive assessment of inflammatory bowel disease and small bowel tumors. MR-colonography can play a role in the detection of large polyps in patients at increased risk of colorectal cancer.
Functional MRI[]
Functional MRI (fMRI) is used to understand how different parts of the brain respond to external stimuli. Blood oxygenation level dependent (BOLD) fMRI measures the hemodynamic response to transient neural activity resulting from a change in the ratio of oxyhemoglobin and deoxyhemoglobin. Statistical methods are used to construct a 3D parametric map of the brain indicating those regions of the cortex which demonstrate a significant change in activity in response to the task. FMRI has applications in behavioral and cognitive research as well as in planning neurosurgery of eloquent brain areas.
Oncology[]
MRI is the investigation of choice in the preoperative staging of colorectal cancer and prostate cancer, and has a role in the diagnosis, staging, and follow-up of other tumors.
How MRI works[]
To perform a study the patient is positioned within an MRI scanner which forms a strong magnetic field around the area to be imaged. In most medical applications protons (hydrogen atoms) in tissues containing water molecules are used to create a signal that is processed to form an image of the body. First energy from an oscillating magnetic field is temporarily applied to the patient at the appropriate resonant frequency. The excited hydrogen atoms emit a radio frequency signal which is measured by a receiver coil. The radio signal can be made to encode position information by varying the main magnetic field using gradient coils. As these coils are rapidly switched on and off they create the characteristic repetitive noises of an MRI scan. The contrast between different tissues is determined by the rate at which excited atoms return to the equilibrium state. Exogenous contrast agents may be given intravenously, orally or intra-articularly.
MRI requires a magnetic field] that is both strong and uniform. The field strength of the magnet is measured in tesla – and while the majority of systems operate at 1.5T, commercial systems are available between 0.2T–7T. Most clinical magnets are superconducting which requires liquid helium. The lower field strengths can be achieved with permanent magnets, which are often used in "open" MRI scanners for claustrophobic patients.
Contrast in MRI[]
Image contrast may be weighted to demonstrate different anatomical structures or pathologies. Each tissue returns to its equilibrium state after excitation by the independent processes of T1 (spin-lattice) and T2 (spin-spin) relaxation.
To create a T1-weighted image more magnetization is allowed to recover before measuring the MR signal by changing the repetition time (TR). This image weighting is useful for assessing the cerebral cortex, identifying fatty tissue, characterizing focal liver lesions and for post-contrast imaging.
To create a T2-weighted image more magnetization is allowed to decay before measuring the MR signal by changing the echo time (TE). This image weighting is useful for detecting edema, revealing white matter lesions and assessing zonal anatomy in the prostate and uterus.
History[]
Magnetic resonance imaging was invented by Paul C. Lauterbur in September 1971; he published the theory behind it in March 1973. The factors leading to image contrast (differences in tissue relaxation time values) had been described nearly 20 years earlier by Erik Odeblad.
In 1952, Herman Carr produced a one-dimensional NMR spectrum as reported in his Harvard PhD thesis. In the Soviet Union, Vladislav Ivanov, filed (in 1960) a document with the USSR State Committee for Inventions and Discovery at Leningrad for a Magnetic Resonance Imaging device, although this was not approved until the 1970s.
In a 1971 paper in the journal Science, Raymond Damadian, an American physician and professor at the Downstate Medical Center State University of New York (SUNY), reported that tumors and normal tissue can be distinguished in vivo by nuclear magnetic resonance ("NMR"). He suggested that these differences could be used to diagnose cancer, though later research would find that these differences, while real, are too variable for diagnostic purposes. Damadian's initial methods were flawed for practical use, relying on a point-by-point scan of the entire body and using relaxation rates, which turned out not to be an effective indicator of cancerous tissue. While researching the analytical properties of magnetic resonance, Damadian created a hypothetical magnetic resonance cancer-detecting machine in 1972. He filed the first patent for such a machine, U.S. patent #3,789,832 on March 17, 1972, which was later issued to him on February 5, 1974.
The National Science Foundation notes "The patent included the idea of using NMR to 'scan' the human body to locate cancerous tissue." However, it did not describe a method for generating pictures from such a scan or precisely how such a scan might be done. Meanwhile, Paul Lauterbur at Stony Brook University expanded on Carr's technique and developed a way to generate the first MRI images, in 2D and 3D, using gradients. In 1973, Lauterbur published the first nuclear magnetic resonance image and the first cross-sectional image of a living mouse in January 1974. In the late 1970s, Peter Mansfield, a physicist and professor at the University of Nottingham, England, developed a mathematical technique that would allow scans to take seconds rather than hours and produce clearer images than Lauterbur had. Damadian, along with Larry Minkoff and Michael Goldsmith, performed the first MRI body scan of a human being on July 3, 1977, studies which they published in 1977. In 1979, Richard S. Likes filed a patent on k-space.
During the 1970s a team led by Scottish professor John Mallard built the first full body MRI scanner at the University of Aberdeen. On 28 August 1980 they used this machine to obtain the first clinically useful image of a patient's internal tissues using Magnetic Resonance Imaging (MRI), which identified a primary tumour in the patient's chest, an abnormal liver, and secondary cancer in his bones. This machine was later used at St Bartholomew's Hospital, in London, from 1983 to 1993. Mallard and his team are credited for technological advances that led to the widespread introduction of MRI.
In 1980 Paul Bottomley joined the GE Research Center in Schenectady, NY, and his team ordered the highest field-strength magnet then available — a 1.5T system — and built the first high-field and overcame problems of coil design, RF penetration and signal-to-noise ratio to build the first whole-body MRI/MRS scanner. The results translated into the highly successful 1.5T MRI product-line, with over 20,000 systems in use today. In 1982, Bottomley performed the first localized MRS in the human heart and brain. After starting a collaboration on heart applications with Robert Weiss at Johns Hopkins, Bottomley returned to the university in 1994 as Russell Morgan Professor and director of the MR Research Division. Although MRI is most commonly performed at 1.5T, higher fields such as 3T are gaining more popularity because of their increased sensitivity and resolution. In research laboratories, human studies have been performed at up to 9.4T and animal studies have been performed at up to 21.1T.
2003 Nobel Prize[]
Reflecting the fundamental importance and applicability of MRI in medicine, Paul Lauterbur of the University of Illinois at Urbana-Champaign and Sir Peter Mansfield of the University of Nottingham were awarded the 2003 Nobel Prize in Physiology or Medicine for their "discoveries concerning magnetic resonance imaging". The Nobel citation acknowledged Lauterbur's insight of using magnetic field gradients to determine spatial localization, a discovery that allowed rapid acquisition of 2D images. Mansfield was credited with introducing the mathematical formalism and developing techniques for efficient gradient utilization and fast imaging. The actual research that won the prize was done almost 30 years before while Paul Lauterbur was a professor in the Department of Chemistry at Stony Brook University in New York.
Safety of MRI[]
Implants[]
All patients are reviewed for contraindications prior to MRI scanning. Medical devices and implants are categorized as MR Safe, MR Conditional or MR Unsafe:
- MR-Safe — The device or implant is completely non-magnetic, non-electrically conductive, and non-RF reactive, eliminating all of the primary potential threats during an MRI procedure.
- MR-Conditional — A device or implant that may contain magnetic, electrically conductive or RF-reactive components that is safe for operations in proximity to the MRI, provided the conditions for safe operation are defined and observed (such as 'tested safe to 1.5 teslas' or 'safe in magnetic fields below 500 gauss in strength').
- MR-Unsafe — Objects that are significantly ferromagnetic and pose a clear and direct threat to persons and equipment within the magnet room.
The MRI environment may cause harm in patients with MR-Unsafe devices such as cochlear implants and most permanent pacemakers. Several deaths have been reported in patients with pacemakers who have undergone MRI scanning without appropriate precautions. Many implants can be safely scanned if the appropriate conditions are adhered to and these are available online (see www.MRIsafety.com). MR Conditional pacemakers are increasingly available for selected patients.
Ferromagnetic foreign bodies such as shell fragments, or metallic implants such as surgical prostheses and ferromagnetic aneurysm clips are also potential risks. Interaction of the magnetic and radio frequency fields with such objects can lead to heating or torque of the object during an MRI.
Titanium and its alloys are safe from attraction and torque forces produced by the magnetic field, though there may be some risks associated with Lenz effect forces acting on titanium implants in sensitive areas within the subject, such as stapes implants in the inner ear.
The very high strength of the magnetic field can also cause "missile-effect" accidents, where ferromagnetic objects are attracted to the center of the magnet, and there have been incidents of injury and death. To reduce the risk of projectile accidents, ferromagnetic objects and devices are typically prohibited in the proximity of the MRI scanner and patients undergoing MRI examinations are required to remove all metallic objects, often by changing into a gown or scrubs, and ferromagnetic detection devices are used at some sites.
EEG Cup Electrodes[]
EEG cup electrodes are categorized as medical accessories and the same MR Safe, MR Conditional and MR Unsafe terminology applies. With the growth of the use of MR technology, the FDA] recognized the need for a consensus on standards of practice, and the FDA sought out ASTM International to achieve them. Working with key stakeholders, Committee F04 of ASTM developed F2503, Standard Practice for Marking Medical Devices and Other Items for Safety in the Magnetic Resonance Environment.
Genotoxic effects[]
There is no proven risk of biological harm from even very powerful static magnetic fields. However, genotoxic (i.e., potentially carcinogenic) effects of MRI scanning have been demonstrated in vivo and in vitro, leading a recent review to recommend "a need for further studies and prudent use in order to avoid unnecessary examinations, according to the precautionary principle". In a comparison of genotoxic effects of MRI compared with those of CT scans, Knuuti et al. reported that even though the DNA damage detected after MRI was at a level comparable to that produced by scans using ionizing radiation (low-dose coronary CT angiography, nuclear imaging, and X-ray angiography), differences in the mechanism by which this damage takes place suggests that the cancer risk of MRI, if any, is unknown.
Peripheral nerve stimulation (PNS)[]
The rapid switching on and off of the magnetic field gradients is capable of causing nerve stimulation. Volunteers report a twitching sensation when exposed to rapidly switched fields, particularly in their extremities. The reason the peripheral nerves are stimulated is that the changing field increases with distance from the center of the gradient coils (which more or less coincides with the center of the magnet). Although PNS was not a problem for the slow, weak gradients used in the early days of MRI, the strong, rapidly switched gradients used in techniques such as EPI, fMRI, diffusion MRI, etc. are capable of inducing PNS. American and European regulatory agencies insist that manufacturers stay below specified dB/dt limits (dB/dt is the change in magnetic field strength per unit time) or else prove that no PNS is induced for any imaging sequence. As a result of dB/dt limitation, commercial MRI systems cannot use the full rated power of their gradient amplifiers.
Heating caused by absorption of radio waves[]
Every MRI scanner has a powerful radio transmitter to generate the electromagnetic field which excites the spins. If the body absorbs the energy, heating occurs. For this reason, the transmitter rate at which energy is absorbed by the body has to be limited.
Acoustic noise[]
Switching of field gradients causes a change in the Lorentz force experienced by the gradient coils, producing minute expansions and contractions of the coil itself. As the switching is typically in the audible frequency range, the resulting vibration produces loud noises (clicking or beeping). This is most marked with high-field machines and rapid-imaging techniques in which sound pressure levels can reach 120 decibels (equivalent to a jet engine at take-off), and therefore appropriate ear protection is essential for anyone inside the MRI scanner room during the examination.
Cryogens[]
Many MRI scanners rely on cryogenic liquids to enable the superconducting capabilities of the electromagnetic coils within. Though the cryogenic liquids used are non-toxic, their physical properties present specific hazards.
An unintentional shut-down of a superconducting electromagnet, an event known as "quench", involves the rapid boiling of liquid helium from the device. If the rapidly expanding helium cannot be dissipated through an external vent, sometimes referred to as a 'quench pipe', it may be released into the scanner room where it may cause displacement of the oxygen and present a risk of suffocation.
Oxygen deficiency monitors are usually used as a safety precaution. Liquid helium, the most commonly used cryogen in MRI, undergoes near explosive expansion as it changes from a liquid to gaseous state. The use of an oxygen monitor is important to ensure that oxygen levels are safe for patients and physicians. Rooms built for superconducting MRI equipment should be equipped with pressure relief mechanisms and an exhaust fan, in addition to the required quench pipe.
Because a quench results in rapid loss of cryogens from the magnet, recommissioning the magnet is expensive and time-consuming. Spontaneous quenches are uncommon, but a quench may also be triggered by an equipment malfunction, an improper cryogen fill technique, contaminants inside the cryostat, or extreme magnetic or vibrational disturbances.
Pregnancy[]
No effects of MRI on the fetus have been demonstrated. In particular, MRI avoids the use of ionizing radiation, to which the fetus is particularly sensitive. However, as a precaution, current guidelines recommend that pregnant women undergo MRI only when essential. This is particularly the case during the first trimester of pregnancy, as organogenesis takes place during this period. The concerns in pregnancy are the same as for MRI in general, but the fetus may be more sensitive to the effects—particularly to heating and to noise. The use of gadolinium-based contrast media in pregnancy is an off-label indication and may only be administered in the lowest dose required to provide essential diagnostic information.
Despite these concerns, MRI is rapidly growing in importance as a way of diagnosing and monitoring congenital defects of the fetus because it can provide more diagnostic information than ultrasound and it lacks the ionizing radiation of CT. MRI without contrast agents is the imaging mode of choice for pre-surgical, in-utero diagnosis and evaluation of fetal tumors, primarily teratomas, facilitating open fetal surgery, other fetal interventions, and planning for procedures (such as the EXIT procedure) to safely deliver and treat babies whose defects would otherwise be fatal.
Claustrophobia and discomfort[]
Despite being painless, MRI scans can be unpleasant for those who are claustrophobic or otherwise uncomfortable with the imaging device surrounding them. Older closed bore MRI systems have a fairly long tube or tunnel. The part of the body being imaged must lie at the center of the magnet, which is at the absolute center of the tunnel. Because scan times on these older scanners may be long (occasionally up to 40 minutes for the entire procedure), people with even mild claustrophobia are sometimes unable to tolerate an MRI scan without management. Some modern scanners have larger bores (up to 70 cm) and scan times are shorter. A 1.5T wide short bore scanner increases the examination success rate in patients with claustrophobia and substantially reduces the need for anesthesia-assisted MRI examinations even when claustrophobia is severe.
Alternative scanner designs, such as open or upright systems, can also be helpful where these are available. Though open scanners have increased in popularity, they produce inferior scan quality because they operate at lower magnetic fields than closed scanners. However, commercial 1.5 tesla open systems have recently become available, providing much better image quality than previous lower field strength open models.
Mirror glasses can be used to help create the illusion of openness. The mirrors are angled at 45 degrees, allowing the patient to look down their body and out the end of the imaging area. The appearance is of an open tube pointing upwards (as seen when lying in the imaging area). Even though one can see around the glasses and the proximity of the device is very evident, this illusion is quite persuasive and relieves the claustrophobic feeling.
For babies and other young children, chemical sedation or general anesthesia are the norm, as these subjects cannot be expected or instructed to hold still during the scanning session. Children are also frequently sedated because they are frightened by the unfamiliar procedure and the loud noises. To reduce anxiety, some hospitals have specially designed child-friendly approaches that pretend the MRI machine is a spaceship or other fun experience.
Obese patients and pregnant women may find the MRI machine to be a tight fit. Pregnant women in the third trimester may also have difficulty lying on their backs for an hour or more without moving.
MRI versus CT[]
MRI and computed tomography (CT) are complementary imaging technologies and each has advantages and limitations for particular applications. CT is more widely used than MRI in OECD countries with a mean of 132 vs 46 exams per 1000 population performed respectively. A concern is the potential for CT to contribute to radiation-induced cancer and in 2007 it was estimated that 0.4% of current cancers in the United States were due to CTs performed in the past, and that in the future this figure may rise to 1.5–2% based on historical rates of CT usage. An Australian study found that one in every 1800 CT scans was associated with an excess cancer. An advantage of MRI is that no ionizing radiation is used and so it is recommended over CT when either approach could yield the same diagnostic information. However, although the cost of MRI has fallen, making it more competitive with CT, there are not many common imaging scenarios in which MRI can simply replace CT, although this substitution has been suggested for the imaging of liver disease. The effect of low doses of radiation on carcinogenesis are also disputed. Although MRI is associated with biological effects, these have not been proven to cause measurable harm. In a comparison of possible genotoxic effects of MRI compared with those of CT scans, Knuuti et al. noted that although previous studies have demonstrated DNA damage associated with MRI, "the long-term biological and clinical significance of DNA double-strand breaks induced by MRI remains unknown".
Iodinated contrast medium is routinely used in CT and the main adverse events are anaphylactoid reactions and nephrotoxicity. Commonly used MRI contrast agents have a good safety profile but linear non-ionic agents in particular have been implicated in nephrogenic systemic fibrosis in patients with severely impaired renal function.
MRI is contraindicated in the presence of MR-unsafe implants, and although these patients may be imaged with CT, beam hardening artefact from metallic devices, such as pacemakers and implantable cardioverter-defibrillators, may also affect image quality. MRI is a longer investigation than CT and an exam may take between 20 - 40 mins depending on complexity.
Guidance[]
Safety issues, including the potential for biostimulation device interference, movement of ferromagnetic bodies, and incidental localized heating, have been addressed in the American College of Radiology's White Paper on MR Safety, which was originally published in 2002 and expanded in 2004. The ACR White Paper on MR Safety has been rewritten and was released early in 2007 under the new title ACR Guidance Document for Safe MR Practices.
In December 2007, the Medicines and Healthcare Products Regulatory Agency (MHRA), a UK healthcare regulatory body, issued their Safety Guidelines for Magnetic Resonance Imaging Equipment in Clinical Use.
In February 2008, the Joint Commission, a U.S. healthcare accrediting organization, issued a Sentinel Event Alert #38, their highest patient safety advisory, on MRI safety issues.
In July 2008, the United States Veterans Administration, a federal governmental agency serving the healthcare needs of former military personnel, issued a substantial revision to their MRI Design Guide, which includes physical and facility safety considerations.
The European Directive on Electromagnetic Fields[]
The Directive (2013/35/EU - electromagnetic fields) covers all known direct biophysical effects and indirect effects caused by electromagnetic fields within the EU and repealed the 2004/40/EC directive. The deadline for implementation of the new directive is 1 July 2016. Article 10 of the directive sets out the scope of the derogation for MRI, stating that the exposure limits may be exceeded during "the installation, testing, use, development, maintenance of or research related to magnetic resonance imaging (MRI) equipment for patients in the health sector, provided that certain conditions are met." Uncertainties remain regarding the scope and conditions of this derogation.
Contrast agents[]
The most commonly used intravenous contrast agents are based on chelates of gadolinium. In general, these agents have proved safer than the iodinated contrast agents used in X-ray radiography or CT. Anaphylactoid reactions are rare, occurring in approx. 0.03–0.1%. Of particular interest is the lower incidence of nephrotoxicity, compared with iodinated agents, when given at usual doses—this has made contrast-enhanced MRI scanning an option for patients with renal impairment, who would otherwise not be able to undergo contrast-enhanced CT.
Although gadolinium agents have proved useful for patients with renal impairment, in patients with severe renal failure requiring dialysis there is a risk of a rare but serious illness, nephrogenic systemic fibrosis, which may be linked to the use of certain gadolinium-containing agents. The most frequently linked is gadodiamide, but other agents have been linked too. Although a causal link has not been definitively established, current guidelines in the United States are that dialysis patients should only receive gadolinium agents where essential, and that dialysis should be performed as soon as possible after the scan to remove the agent from the body promptly. In Europe, where more gadolinium-containing agents are available, a classification of agents according to potential risks has been released. Recently, a new contrast agent named gadoxetate, brand name Eovist (U.S.) or Primovist (EU), was approved for diagnostic use: this has the theoretical benefit of a dual excretion path.
Health economics[]
In the UK, the price of a clinical 1.5 tesla MRI scanner is around €1,04 million with the lifetime maintenance cost broadly similar to the purchase cost. In the Netherlands, the average MRI scanner costs around €1 million, with a 7T MRI having been taken in use by the UMC Utrecht in December 2007, costing €7 million. Construction of MRI suites could cost up to €370.000 or more, depending on project scope. Pre-polarizing MRI (PMRI) systems using resistive electromagnets have shown promise as a low cost alternative and have specific advantages for joint imaging near metal implants, however they are unlikely to be suitable for routine whole-body or neuroimaging applications.
MRI scanners have become significant sources of revenue for healthcare providers in the U.S.. This is because of favorable reimbursement rates from insurers and federal government programs. Insurance reimbursement is provided in two components, an equipment charge for the actual performance and operation of the MRI scan and a professional charge for the radiologist's review of the images and/or data. In the U.S. Northeast, an equipment charge might be $3,500 and a professional charge might be $350 although the actual fees received by the equipment owner and interpreting physician are often significantly less and depend on the rates negotiated with insurance companies or determined by the Medicare fee schedule. For example, an orthopedic surgery group in Illinois billed a charge of $1,116 for a knee MRI in 2007, but the Medicare reimbursement in 2007 was only $470.91. Many insurance companies require advance approval of an MRI procedure as a condition for coverage.
In the U.S., the Deficit Reduction Act of 2005 significantly reduced reimbursement rates paid by federal insurance programs for the equipment component of many scans, shifting the economic landscape. Many private insurers have followed suit.
In the United States, an MRI of the brain with and without contrast billed to Medicare Part B entails, on average, a technical payment of $403 and a separate payment to the radiologist of $93. In France, the cost of an MRI exam is approximately €150. This covers three basic scans including one with an intravenous contrast agent as well as a consultation with the technician and a written report to the patient's physician. In Japan, the cost of an MRI examination (excluding the cost of contrast material and films) ranges from €115 to €133, with an additional radiologist professional fee of €12,50. In India, the cost of an MRI examination including the fee for the radiologist's opinion comes to around Rs 3000–4000, excluding the cost of contrast material. In the UK the retail price for an MRI scan privately ranges between £350 and £500.
Overuse[]
Medical societies issue guidelines for when physicians should use MRI on patients and recommend against overuse. MRI can detect health problems or confirm a diagnosis, but medical societies often recommend that MRI not be the first procedure for creating a plan to diagnose or manage a patient's complaint. A common case is to use MRI to seek a cause of low back pain; the American College of Physicians, for example, recommends against this procedure as unlikely to result in a positive outcome for the patient.
Specialized applications[]
Diffusion MRI[]
Diffusion MRI measures the diffusion of water molecules in biological tissues. Clinically, diffusion MRI is useful for the diagnoses of conditions (e.g., stroke) or neurological disorders (e.g., multiple sclerosis), and helps better understand the connectivity of white matter axons in the central nervous system. In an isotropic medium (inside a glass of water for example), water molecules naturally move randomly according to turbulence and Brownian motion. In biological tissues however, where the Reynolds number is low enough for flows to be laminar, the diffusion may be anisotropic. For example, a molecule inside the axon of a neuron has a low probability of crossing the myelin membrane. Therefore the molecule moves principally along the axis of the neural fiber. If it is known that molecules in a particular voxel diffuse principally in one direction, the assumption can be made that the majority of the fibers in this area are parallel to that direction.
The recent development of diffusion tensor imaging (DTI) enables diffusion to be measured in multiple directions and the fractional anisotropy in each direction to be calculated for each voxel. This enables researchers to make brain maps of fiber directions to examine the connectivity of different regions in the brain (using tractography) or to examine areas of neural degeneration and demyelination in diseases like multiple sclerosis.
Another application of diffusion MRI is diffusion-weighted imaging (DWI). Following an ischemic stroke, DWI is highly sensitive to the changes occurring in the lesion. It is speculated that increases in restriction (barriers) to water diffusion, as a result of cytotoxic edema (cellular swelling), is responsible for the increase in signal on a DWI scan. The DWI enhancement appears within 5–10 minutes of the onset of stroke symptoms (as compared to computed tomography, which often does not detect changes of acute infarct for up to 4–6 hours) and remains for up to two weeks. Coupled with imaging of cerebral perfusion, researchers can highlight regions of "perfusion/diffusion mismatch" that may indicate regions capable of salvage by reperfusion therapy.
Like many other specialized applications, this technique is usually coupled with a fast image acquisition sequence, such as echo planar imaging sequence.
Magnetic resonance angiography[]
Magnetic resonance angiography (MRA) generates pictures of the arteries to evaluate them for stenosis (abnormal narrowing) or aneurysms (vessel wall dilatations, at risk of rupture). MRA is often used to evaluate the arteries of the neck and brain, the thoracic and abdominal aorta, the renal arteries, and the legs (called a "run-off"). A variety of techniques can be used to generate the pictures, such as administration of a paramagnetic contrast agent (gadolinium) or using a technique known as "flow-related enhancement" (e.g., 2D and 3D time-of-flight sequences), where most of the signal on an image is due to blood that recently moved into that plane. Techniques involving phase accumulation (known as phase contrast angiography) can also be used to generate flow velocity maps easily and accurately. Magnetic resonance venography (MRV) is a similar procedure that is used to image veins. In this method, the tissue is now excited inferiorly, while the signal is gathered in the plane immediately superior to the excitation plane—thus imaging the venous blood that recently moved from the excited plane.
Magnetic resonance spectroscopy[]
Magnetic resonance spectroscopy (MRS) is used to measure the levels of different metabolites in body tissues. The MR signal produces a spectrum of resonances that corresponds to different molecular arrangements of the isotope being "excited". This signature is used to diagnose certain metabolic disorders, especially those affecting the brain, and to provide information on tumor metabolism.
Magnetic resonance spectroscopic imaging (MRSI) combines both spectroscopic and imaging methods to produce spatially localized spectra from within the sample or patient. The spatial resolution is much lower (limited by the available signal-to-noise ratio), but the spectra in each voxel contains information about many metabolites. Because the available signal is used to encode spatial and spectral information, MRSI requires high SNR achievable only at higher field strengths (3 T and above).
Functional MRI[]
Functional MRI (fMRI) measures signal changes in the brain that are due to changing neural activity. Compared to anatomical T1W imaging, the brain is scanned at lower spatial resolution but at a higher temporal resolution (typically once every 2–3 seconds). Increases in neural activity cause changes in the MR signal via T changes; this mechanism is referred to as the BOLD (blood-oxygen-level dependent) effect. Increased neural activity causes an increased demand for oxygen, and the vascular system actually overcompensates for this, increasing the amount of oxygenated hemoglobin relative to deoxygenated hemoglobin. Because deoxygenated hemoglobin attenuates the MR signal, the vascular response leads to a signal increase that is related to the neural activity. The precise nature of the relationship between neural activity and the BOLD signal is a subject of current research. The BOLD effect also allows for the generation of high resolution 3D maps of the venous vasculature within neural tissue.
While BOLD signal analysis is the most common method employed for neuroscience studies in human subjects, the flexible nature of MR imaging provides means to sensitize the signal to other aspects of the blood supply. Alternative techniques employ arterial spin labeling (ASL) or weighting the MRI signal by cerebral blood flow (CBF) and cerebral blood volume (CBV). The CBV method requires injection of a class of MRI contrast agents that are now in human clinical trials. Because this method has been shown to be far more sensitive than the BOLD technique in preclinical studies, it may potentially expand the role of fMRI in clinical applications. The CBF method provides more quantitative information than the BOLD signal, albeit at a significant loss of detection sensitivity.
Real-time MRI[]
Real-time MRI refers to the continuous monitoring ("filming") of moving objects in real time. While many different strategies have been developed over the past two decades, a recent development reported a real-time MRI technique based on radial FLASH and iterative reconstruction that yields a temporal resolution of 20 to 30 milliseconds for images with an in-plane resolution of 1.5 to 2.0mm. The new method promises to add important information about diseases of the joints and the heart. In many cases MRI examinations may become easier and more comfortable for patients.
Interventional MRI[]
The lack of harmful effects on the patient and the operator make MRI well-suited for "interventional radiology", where the images produced by an MRI scanner are used to guide minimally invasive procedures. Of course, such procedures must be done without any ferromagnetic instruments.
A specialized growing subset of interventional MRI is that of intraoperative MRI in which the MRI is used in the surgical process. Some specialized MRI systems have been developed that allow imaging concurrent with the surgical procedure. More typical, however, is that the surgical procedure is temporarily interrupted so that MR images can be acquired to verify the success of the procedure or guide subsequent surgical work.
Magnetic resonance guided focused ultrasound[]
In MRgFUS therapy, ultrasound beams are focused on a tissue—guided and controlled using MR thermal imaging—and due to the significant energy deposition at the focus, temperature within the tissue rises to more than 65°C (150°F), completely destroying it. This technology can achieve precise ablation of diseased tissue. MR imaging provides a three-dimensional view of the target tissue, allowing for precise focusing of ultrasound energy. The MR imaging provides quantitative, real-time, thermal images of the treated area. This allows the physician to ensure that the temperature generated during each cycle of ultrasound energy is sufficient to cause thermal ablation within the desired tissue and if not, to adapt the parameters to ensure effective treatment.
Multinuclear imaging[]
Hydrogen is the most frequently imaged nucleus in MRI because it is present in biological tissues in great abundance, and because its high gyromagnetic ratio gives a strong signal. However, any nucleus with a net nuclear spin could potentially be imaged with MRI. Such nuclei include helium-3, lithium-7, carbon-13, fluorine-19, oxygen-17, sodium-23, phosphorus-31, and xenon-129. 23Na and 31P are naturally abundant in the body, so can be imaged directly. Gaseous isotopes such as 3He or 129Xe must be hyperpolarized and then inhaled as their nuclear density is too low to yield a useful signal under normal conditions. 17O and 19F can be administered in sufficient quantities in liquid form (e.g. 17O-water) that hyperpolarization is not a necessity.
Moreover, the nucleus of any atom that has a net nuclear spin and that is bonded to a hydrogen atom could potentially be imaged via heteronuclear magnetization transfer MRI that would image the high-gyromagnetic-ratio hydrogen nucleus instead of the low-gyromagnetic-ratio nucleus that is bonded to the hydrogen atom. In principle, hetereonuclear magnetization transfer MRI could be used to detect the presence or absence of specific chemical bonds.
Multinuclear imaging is primarily a research technique at present. However, potential applications include functional imaging and imaging of organs poorly seen on 1H MRI (e.g., lungs and bones) or as alternative contrast agents. Inhaled hyperpolarized 3He can be used to image the distribution of air spaces within the lungs. Injectable solutions containing 13C or stabilized bubbles of hyperpolarized 129Xe have been studied as contrast agents for angiography and perfusion imaging. 31P can potentially provide information on bone density and structure, as well as functional imaging of the brain. Multinuclear imaging holds the potential to chart the distribution of lithium in the human brain, this element finding use as an important drug for those with conditions such as bipolar disorder.
Molecular imaging by MRI[]
MRI has the advantages of having very high spatial resolution and is very adept at morphological imaging and functional imaging. MRI does have several disadvantages though. First, MRI has a sensitivity of around 10−3 mol/L to 10−5 mol/L which, compared to other types of imaging, can be very limiting. This problem stems from the fact that the difference between atoms in the high energy state and the low energy state is very small. For example, at 1.5 teslas, a typical field strength for clinical MRI, the difference between high and low energy states is approximately 9 molecules per 2 million. Improvements to increase MR sensitivity include increasing magnetic field strength, and hyperpolarization via optical pumping or dynamic nuclear polarization. There are also a variety of signal amplification schemes based on chemical exchange that increase sensitivity.
To achieve molecular imaging of disease biomarkers using MRI, targeted MRI contrast agents with high specificity and high relaxivity (sensitivity) are required. To date, many studies have been devoted to developing targeted-MRI contrast agents to achieve molecular imaging by MRI. Commonly, peptides, antibodies, or small ligands, and small protein domains, such as HER-2 affibodies, have been applied to achieve targeting. To enhance the sensitivity of the contrast agents, these targeting moieties are usually linked to high payload MRI contrast agents or MRI contrast agents with high relaxivities. A new class of gene targeting MR contrast agents (CA) has been introduced to show gene action of unique mRNA and gene transcription factor proteins. This new CA can trace cells with unique mRNA, microRNA and virus; tissue response to inflammation in living brains. The MR reports change in gene expression with positive correlation to TaqMan analysis, optical and electron microscopy.
Other specialized sequences[]
New methods and variants of existing methods are often published when they are able to produce better results in specific fields. Examples of these recent improvements are TTemplate:Su-weighted turbo spin-echo (T2 TSE MRI), double inversion recovery MRI (DIR-MRI) or phase-sensitive inversion recovery MRI (PSIR-MRI), all of them able to improve imaging of brain lesions. Another example is MP-RAGE (magnetization-prepared rapid acquisition with gradient echo), which improves images of multiple sclerosis cortical lesions.
Magnetization transfer MRI[]
Magnetization transfer (MT) is a technique to enhance image contrast in certain applications of MRI.
Bound protons are associated with proteins and as they have a very short T2 decay they do not normally contribute to image contrast. However, because these protons have a broad resonance peak they can be excited by a radiofrequency pulse that has no effect on free protons. Their excitation increases image contrast by transfer of saturated spins from the bound pool into the free pool, thereby reducing the signal of free water. This homonuclear magnetization transfer provides an indirect measurement of macromolecular content in tissue. Implementation of homonuclear magnetization transfer involves choosing suitable frequency offsets and pulse shapes to saturate the bound spins sufficiently strongly, within the safety limits of specific absorption rate for MRI.
The most common use of this technique is for suppression of background signal in time of flight MR angiography. There are also applications in neuroimaging particularly in the characterization of white matter lesions in multiple sclerosis.
T1rho MRI[]
T1ρ (T1rho): Molecules have a kinetic energy that is a function of the temperature and is expressed as translational and rotational motions, and by collisions between molecules. The moving dipoles disturb the magnetic field but are often extremely rapid so that the average effect over a long time-scale may be zero. However, depending on the time-scale, the interactions between the dipoles do not always average away. At the slowest extreme the interaction time is effectively infinite and occurs where there are large, stationary field disturbances (e.g., a metallic implant). In this case the loss of coherence is described as a "static dephasing". T2* is a measure of the loss of coherence in an ensemble of spins that includes all interactions (including static dephasing). T2 is a measure of the loss of coherence that excludes static dephasing, using a RF pulse to reverse the slowest types of dipolar interaction. There is in fact a continuum of interaction time-scales in a given biological sample, and the properties of the refocusing RF pulse can be tuned to refocus more than just static dephasing. In general, the rate of decay of an ensemble of spins is a function of the interaction times and also the power of the RF pulse. This type of decay, occurring under the influence of RF, is known as T1ρ. It's similar to T2 decay but with some slower dipolar interactions refocused, as well as static interactions, hence T1ρ≥T2.
Fluid attenuated inversion recovery (FLAIR)[]
Fluid Attenuated Inversion Recovery (FLAIR) is an inversion-recovery pulse sequence used to nullify the signal from fluids. For example, it can be used in brain imaging to suppress cerebrospinal fluid (CSF) so as to bring out periventricular hyperintense lesions, such as multiple sclerosis (MS) plaques. By carefully choosing the inversion time TI (the time between the inversion and excitation pulses), the signal from any particular tissue can be suppressed.
Susceptibility weighted imaging (SWI)[]
Susceptibility weighted imaging (SWI), is a new type of contrast in MRI different from spin density, T1, or T2 imaging. This method exploits the susceptibility differences between tissues and uses a fully velocity compensated, three dimensional, RF spoiled, high-resolution, 3D gradient echo scan. This special data acquisition and image processing produces an enhanced contrast magnitude image very sensitive to venous blood, hemorrhage and iron storage. It's used to enhance the detection and diagnosis of tumors, vascular and neurovascular diseases (stroke and hemorrhage), multiple sclerosis, Alzheimer's disease, and also detects traumatic brain injuries that may not be diagnosed using other methods.
Neuromelanin imaging[]
This method exploits the paramagnetic properties of neuromelanin and can be used to visualize the substantia nigra and the locus coeruleus. It is used to detect the atrophy of these nuclei in Parkinson's disease and other parkinsonisms, and also detects signal intensity changes in major depressive disorder and schizophrenia.
On the series[]
Magnetic resonance imaging is one of the most common diagnostic procedures shown on the series. However, the depiction of the procedure on the show is often misleading. In reality, hospital MRIs are usually fully utilized throughout the working day and obtaining time to use one is strictly controlled. Although exceptions are made for emergencies, even patients who can use one often have to wait for days to be scheduled. In addition, MRIs are performed almost entirely by specialized technicians, not by physicians. Moreover, while attending physicians usually get copies of all the scans, in most cases a specialized radiologist reviews the scans and reports to the attending.
As noted in the main part of the article, MRIs are noisy machines. Although the MRI room is often used for character dialogue, in reality it would be difficult to carry out a conversation in the MRI room. Most people who work with MRI have to wear ear protection as a matter of course.
Season 1[]
- In the Pilot, Rebecca Adler's first attempt at an MRI is interrupted when House's hospital privileges are suspended. When they finally did perform it, Rebecca suffered an adverse reaction to the contrast material.
- In Paternity, a review of Dan's seemingly normal MRI showed a bowed corpus callosum, which eventually led to the right diagnosis.
- They performed an MRI on the sick infants in Maternity, but found nothing. As noted in the main article, this is a fairly dangerous procedure as the babies would have had to been anesthetized in order to undergo the procedure.
- In Fidelity, they performed an MRI on Elise Snow looking for a small tumor. House noted, correctly, that a tumor that didn't show up on a contrast MRI was too small to cause any symptoms.
- In DNR, John Henry Giles initially refused to consent to the procedure, but House eventually talked him into it. However, that MRI found nothing. However, House later repeated the procedure after giving John Henry steroids, on which he had previously improved. This reduced swelling that was hiding an arteriovenous malformation which was found on a subsequent MRI and explained all the symptoms that had been mistaken for ALS.
- Histories had a lot of elements surrounding the MRI. In order to scan Victoria Madsen, then a Jane Doe patient, Foreman waylaid the patient who had been scheduled for one of the time slots. However, Cuddy found out about the deception and then admonished Foreman for not noticing a surgical pin that had showed up on a CT scan - the MRI would have ripped it out. She noted, quite correctly, that giving an MRI without a complete medical history was dangerous in any event. However, House insisted they had to do the MRI to rule out a brain tumor. They then removed the pin surgically. The subsequent MRI was indeed clear but it revealed House's ulterior motive - the surgical pin had a serial number on it and House was able to trace the patient's medical history from the pin's manufacturer.
- In Sports Medicine, Wilson had already given Hank Wiggen an MRI to look for cancer before giving the case to House.
- In Control, Chase does an MRI on Carly Forlano's spine to look for a disc herniation
- In Mob Rules, an MRI of Joey Arnello found a subdural hematoma.
- After realizing Jessica Simms might have Cushing's disease in the episode Heavy, House orders an MRI which finds a cortisol producing tumor on the pituitary.
- After noticing that Senator Gary H. Wright had abnormal reflexes during his physical exam, House orders Foreman to do an MRI of the brain. The MRI showed a very small lesion. House wanted to do a biopsy, but Cuddy forbade it due to the risk of brain damage. However, House obtained consent from the patient and proceeded with the biopsy. The biopsy showed that it was a toxoplasmosis infection, which meant that the Senator had AIDS.
- In Love Hurts, House wants to do an MRI of Harvey Park, but Cameron informs him that's impossible because Harvey has a metal plate in his jaw, the result of a severe fracture.
- In Three Stories, the Rebellious Student suggests they give The Farmer an MRI to look for the cause of his leg pain. Cameron goes looking for an adenoma to explain the Volleyball Player's symptoms and, after using an MRI to look for it near her problematic thyroid, she does a second MRI and finds it in her leg. Finally, after days of excruciating leg pain, Mid 30s man suggests he might be suffering from muscle death and the doctors finally do an MRI which finds an aneurysm that has clotted.
Season 2[]
- In Acceptance, the team has to do an MRI on Clarence despite the pain caused by the metallic inks in his tattoos. However, although this is a real complication, it is very rare that it actually happens. In those rare cases, the ink heats up and, when it does happen, the proper procedure is to immediately stop the machine. However, it turned out to be worth it as they found a pheochromocytoma.
- In Autopsy, House orders an MRI on Andie right away to look for an infection. Although Chase offered to turn on the projection screen, Andie had been in the MRI several times before and was used to the procedure. However, the scan missed a tumor that was growing along the heart wall which they found during exploratory surgery after finding an irregularity in the sound of her mitral valve. Later, during the reprofusion procedure, they use a portable machine to track the blood flowing back into her brain.
- In Humpty Dumpty, Cuddy ordered House's team to do a cervical MRI of Alfredo to look for evidence of DIC.
- In TB or Not TB, House ordered an MRI of Sebastian Charles when Foreman suggested that Charles might have a brain tumor.
- Prior to reaching House in the episode Daddy's Boy, Carnell Hall had been given an MRI to confirm an initial diagnosis of multiple sclerosis. However, the MRI found no white matter lesions.
- After Kayla McGinley takes a turn for the worse after her liver transplant, House finds out her brother and donor had hepatitis. He orders an MRI on both of them to find that they both had a hepatoma that was transferred along with the transplanted lobe of the liver.
- When Foreman is in charge in Deception, he orders House to do a full workup of Anica Jovanovich, including an MRI. However, they find nothing on the MRI.
- In Failure to Communicate, House, who is stuck in Baltimore, orders his team to perform an MRI, but when he calls back, it hasn't been done yet because they haven't "cheated" and stolen someone's appointment. When they do it, it shows edema and scarring. This is later explained by radiosurgery when Stone tried to correct his bipolar disorder.
- In Need to Know, Margo Dalton refused an MRI until her pregnancy test came back negative. However, once the test was negative, they did the MRI and it was clear.
- In Distractions, they couldn't perform an MRI on Adam because he couldn't be moved from his clean room to radiology.
- In Skin Deep, Alexandria Robinson was given an MRI to rule out brain damage after her heart attack, but as she couldn't stop twitching during the procedure, the results were inconclusive.
- In Sex Kills, Henry Arrington was given an MRI before he reached House, but it was clean.They also gave an MRI to the late Laura Neuberger to look for an infection in her gallbladder.
- In Safe, Cuddy ordered an MRI of Melinda Bardach after she removed House from the case to look for spinal lesions which might be causing her rapidly progressing paralysis.
- In All In, House orders an MRI of Ian Alston, who is scarred of the machine and has to be comforted by his mother. However, the MRI provides the team with no clues.
- In House vs. God, House orders an MRI of Boyd because his symptoms fit both a brain tumor and tuberous sclerosis. Boyd takes the opportunity during the MRI to ask Chase why he did things he didn't want to do. The scan confirmed tuberous sclerosis and that the voice Boyd heard (and interpreted as God speaking to him) was caused by the growth.
- In Euphoria (Part 1), House thought Joe Luria might have a clot in his brain and wanted to do an MRI. However, Luria had been wounded and there were steel bullet fragments in his head, so his team told him it was impossible. To try to prove them wrong, House procured a corpse, shot it, then put it in the MRI machine. The machine immediately tore the bullets out of the corpse, breaking the machine. When Foreman started showing the same symptoms, House got the portable MRI. Although that scan showed an abnormality in the singular cortex that pointed to an infection. When Foreman started running a fever, he insisted on being treated with antibiotics for staphylococcus.
- In Forever, House ordered an MRI for Kara Mason believing she had meningitis. However, instead, they found a subarachnoid hemorrhage.
- In Who's Your Daddy?, House ordered an MRI on Leona to confirm hemochromatosis. Foreman performs the procedure and confirms the diagnosis.
Season 3[]
- In Meaning, Caren Krause has already had an MRI before she reaches House which has ruled out any swelling of her spinal discs which could have caused her paralysis.
- In Cane & Able, once they figure out Clancy Green has two different types of DNA, they use a tagging agent to mark the foreign DNA, then put Clancy in an MRI to find it. However, it did not reveal any foreign DNA in his brain because of the blood-brain barrier. As such, they have to put the tagging agent directly into his brain, make him have hallucinations and once again use a fMRI to find the foreign DNA.
- In Que Será Será, Cameron defies House and insists the rest of the team assist her with an MRI of the morbidly obsese George despite the fact he weighs far more than the table is designed to hold. Although the MRI starts normally, George suddenly regains consciousness during the procedure, panics, and his movements cause the table to collapse. In any event, the MRI showed no abnormalities.
- The team performs an MRI on Son of Coma Guy Kyle Wozniak, but finds nothing conclusive.
- In Whac-A-Mole, Foreman believes that Jack Walters may have a tumor and orders an MRI. However, the MRI is clean.
- In Merry Little Christmas, after Cuddy dismisses House from the case, she orders an MRI of Abigail Ralphean to look for masses. The scan was clean, but after they finished the scan, she started vomiting blood.
- In Words and Deeds, after Derek Hoyt doesn't improve after electroshock therapy and they realize he was suffering from delusions, Foreman orders an MRI that shows hypoprofusion in the anterior cingulate cortex.
- When House manages to dodge clinic duty by treating the Ear Patient in One Day, One Room, he ordered a battery of tests including an MRI to pretend he was busy on the case when in fact he had already figured out the man had an insect in his ear.
- In Needle in a Haystack, they gave Stevie Lipa an MRI to look for the cause of his abdominal pain. They found a granuloma which indicated granulomatosis with polyangiitis but didn't find the real problem - a swallowed toothpick which was invisible on the MRI because it was the same density as the surrounding tissue. In fact, although a toothpick might be spotted on an MRI, depending on it's angle, it may just appear as a small dot that would be easy to miss. A toothpick would certainly not show up on a X-ray as they're X-ray transparent.
- In Insensitive, Hannah Morgenthal is first given a fMRI while she alternately places her hand in hot and cold water, but she accidentally scalds herself in the process. A second MRI is used to look for a clot with no success. House is about to give her another MRI when he realizes her symptoms get worse when she is given nitrous oxide.
- In Half-Wit, House gave Patrick Obyedkov, a musical savant, a fMRI to attempt to determine the source of his musical talent.
- In Fetal Position, Emma Sloan is given an MRI to see if there is calcification of her mitral valve. The MRI does find the calcification, but treating it doesn't help. The next MRI is of the fetus, which finds an enlarged bladder. However, treating this didn't help either. When they finally figured out it was related to maternal mirror syndrome, they realized that an MRI wouldn't give them enough detail and they had to resort to exploratory surgery.
- In Act Your Age, House was sure that Lucy had an ovarian tumor that was causing her hormone imbalances. An MRI showed he was right, but Lucy's symptoms persisted after it was removed.
- In House Training, House ordered an MRI on Lupe which found a mass that a biopsy showed was white blood cells. This led them to the incorrect conclusion that she had an autoimmune disease.
- In Resignation, Foreman did an MRI on Addie looking for a clot or tumor and, at House's insistence, an abscess. Although the scan was clean, when they took her out of the machine, her scalp had split wide open.
- In Human Error, the first procedure House ordered on Marina Hernandez was an MRI as he figured her Cuban doctors, who were otherwise competent, wouldn't have had access to one. It found symptoms leading to the conclusion that she had multiple sclerosis.
Season 4[]
- In Alone, House realized that Megan Bradberry can't have hypothalamic dysregulation as that would have shown up on an MRI. Later, when he diagnoses her with pancreatitis, Cuddy insists he do an MRI to confirm. He finally complies, but finds his diagnosis was wrong. However, he does find evidence that she has internal bleeding. When Cuddy cuts off his ability to do more procedures, he fakes a memo to Dr. Imelda who performs one and finds granulomas that point to an allergic reaction to the antibiotics that she had been given.
- In The Right Stuff, House orders Thirteen, Jodi Desai, and Chris Taub to do an MRI on Greta Cooper. However, that scan was clean. Later, he wants to do an MRI on her when he suspects cancer, but by that point he has to chart all procedures and Cooper will not consent to any procedure that has to be charted due to her fear NASA will start asking questions.
- In Guardian Angels, House orders an MRI with contrast on Irene, but it shows no abnormalities.
- In Whatever It Takes, before House leaves, he orders the team to do an MRI. However, Foreman overrules House once House leaves as he thinks it's just dehydration.
- In You Don't Want to Know, Lawrence Kutner bets his job on the fact that his patient Flynn is seriously ill. Desperate to find something wrong with him, Foreman suggests he do an MRI to look for a fungus in the patient's lungs. Kutner thinks that the emergency room would have seen it, but Foreman suggests they may have missed it. Kutner gets Flynn's consent, but when they start the procedure, he gets a stabbing pain in his abdomen. It turns out he had, years ago, swallowed a lock pick, so the MRI told them nothing. Later, they do another MRI to look for a tumor. They only find a dark spot where the lock pick came through, but they also spot signs of internal bleeding.
- In It's a Wonderful Lie, House starts with an MRI of Maggie Archer to rule out breast cancer despite her mastectomy. However, the scan is clear. He does another MRI looking for multiple sclerosis, but that one is clear as well.
- In Don't Ever Change, House orders an MRI on Roz to look for a blood clot in her leg and a fMRI to look for signs of a stroke. The MRI was normal, but House used the fMRI to check if Roz had signs of masochism. Although her pleasure centers lit up when she was stuck with a needle, it was because she had been praying before it happened. When she got up off the MRI table, her heart rate and blood pressure dropped suddenly even though a normal reaction would have been for them to go up instead.
- In No More Mr. Nice Guy, House is looking for a reason why Jeff is unusually nice and orders an MRI. However, it's clear. He then thinks it might be syphillis, and orders a contrast MRI. The patient seems to have syphillis, but Kutner is unconvinced. He realized that if Jeff had encephalitis, it would have been hidden by the steroids they gave him. He took him off steroids and gave him another MRI which confirmed the encephalitis.
- In Living The Dream, House is convinced that Evan Greer has a brain tumor. When he can't get Greer to consent to the procedure, he sedates him and orders his team to do it. However, the MRI is clean.
Season 5[]
- In Adverse Events, although his MRI on admission was clean, House orders an MRI with contrast. However, it was clean as well.
- In Birthmarks, House wants to do an MRI on Nicole to look for blood clots in her brain. However, the MRI is delayed when she vomits before the procedure starts. House orders them to continue, but calls back to stop it once he realizes her symptoms have been caused by pins inserted into her skull when she was an infant in an attempt to kill her.
- In The Itch, Cameron wants to do an MRI on Stewart Nozick to look for the source of his intestinal blockage, but he refuses to be taken to the hospital.
- In Emancipation, House orders Foreman do to an MRI on Sophia Isabel Velez himself in order to keep him away from another case. However, he gets one of the other fellows to set up the MRI, but appears once the patient is ready. However the fMRI shows no abnormalities. However, when Thirteen does another scan later, she finds lesions that weren't on the first scan.
- In Last Resort, Jason has already had two full body MRI scans that were clear.
- In Let Them Eat Cake, House orders an MRI on Emmy to look for a carcinoid tumor. Instead, they find evidence that Emmy has undergone a gastric banding procedure that she did not list on her medical history. Later, they did another MRI of her brain to look for CNS lymphoma, but that scan was clear.
- In Painless, House orders an MRI on Jeff to look for a tumor that may be causing his intense pain. They don't find a tumor, but do find edema in his intestines.
- In Big Baby, House wanted to do a brain biopsy on Sarah to look for multiple sclerosis, but Cameron, who was supervising him, insisted he perform an MRI. He did, and it did not show any evidence of the plaques typical of the disease.
- In The Greater Good, Taub had performed an MRI on Dana Miller which had ruled out any pathology of the liver. Later, House ordered another MRI of her brain to look for a brain tumor, but the scan was clean.
- In The Softer Side, House is being affected by the methadone he is taking for his pain and quickly agrees to give Jackson Smith a contrast MRI to look for a blind uterus at the request of his parents. When Jackson gets worse, House finally realizes Jackson's symptoms are the result of receiving contrast while he was suffering from dehydration.
- In The Social Contract, the initial MRI of Nick Greenwald showed no tumor in his head, but could not rule out a tumor in his nasal cavities, so House ordered an examination of the nose. However, that was clean as well. House then ordered a fMRI to see if Nick's frontal lobe disinhibition could have been due to brain damage. The scan showed no damage, but also did not show any activity in the cingulate gyrus, which pointed to sarcoidosis.
- In Here Kitty, Foreman did an MRI of Morgan West looking for evidence of Cushing's syndrome, but found no evidence of it.
- In Locked In, House faked a requisition to give an MRI to Lee, who he though might have a brain tumor. He found a lesion in the central pons which seemed to confirm his diagnosis.
- In Simple Explanation, House ordered an MRI of Charlotte Novack to look for multiple sclerosis. The MRI didn't show any evidence of MS, but during the procedure, her spleen ruptured, which coincidentally ruled out MS.
- In House Divided, House orders an MRI of Seth Miller looking for a slow growing brain tumor. The scan shows no tumor, but does show increased intracranial pressure. In addition, House finds an MRI taken three years previously, which doesn't show the bowing that appears in the current scans. This justifies a brain biopsy, but it shows no abnormal result.
- In Under My Skin, House is trying to find a way to test Penelope, whose heart rhythm is abnormal. He hits upon the idea of stopping her heart and giving her an MRI while it's stopped. The team agrees, but after three minutes, they have to revive her. The only abnormality found was a small shadow on the aorta.
- In Both Sides Now, House orders a scan of Scott to look for cancer on his pancreas. Wilson does the scan and uses the opportunity to help Scott overcome his alien hand syndrome.
Season 6[]
- In Epic Fail, Vince Pearson insists on an MRI to check for a brain tumor despite Foreman advising against it. The scan is clean but when he suffers an adverse reaction to the contrast material, this is initially seen as a new symptom.
- In Known Unknowns, Foreman orders a scan of Jordan to look for clots and obstructions, but the scan is clear.
- In Ignorance is Bliss, House gives James Sidas a contrast MRI to show if his spleen is still there even though Chase had removed it surgically. The scan shows several break-off spleens from a previous injury that also have to be removed.
- In The Down Low, House thinks that Mickey might have a tumor on his adrenal glands and orders an MRI. However, the scan is clear.
- In Remorse, Dr. Hadley did an fMRI on Valerie which confirmed her suspicions that the patient was a psychopath. Later though, this same test ruled out amyloidosis.
- In Moving the Chains, House thought Daryl might have a problem with his pituitary and ordered an MRI. However, the scan was normal.
- In Black Hole, Chase realized that House would want a contrast MRI on Abby Nash to check her lactic acid levels. However, during the procedure, he and Taub spotted an abnormality on her mitral valve. They did another MRI to check her temporal-parietal junction, but it was clear. Later, they did another MRI to check her pineal gland, but it was clear as well.
- In Knight Fall, they do an MRI on Sir William looking for a hematoma, but they don't find a hematoma or any other abnormality.
- In Open and Shut, they do an MRI on Julia looking for an adrenal carcinoma, but her adrenal glands are clean.
- In The Choice, House does an MRI on Theodore Philip Taylor looking for a tumor on his pituitary, but the scan is clear.
- In Baggage, Sidney Merrick had been given an MRI as part of her work-up before her case was referred to House, but it showed no abnormalities.
- In Help Me, House orders an MRI on Jay Dolce looking for a lesion in his brain despite the chance that any trauma will interfere with the results. However, the scan is clear.
Season 7[]
- In Unwritten, House orders an MRI on Alice Tanner looking for a pheochromocytoma. However, when they tried to give her the scan, sparks shot out of her calf due to a steel plate that had been inserted there years before to fix a fractured leg. Tanner had deliberately withheld this information in a suicide attempt. However, House found another use for the MRI. Together with Sam Carr, he used it to scan Tanner's typewriter ribbon to reconstruct a copy of her last manuscript.
- In Small Sacrifices, House believes that Ramon Silva is suffering from a neurological disorder and orders an MRI. It discovers the lesions typical of multiple sclerosis.
- In Carrot or Stick, House orders an MRI on Driscoll believing he might have a pheochromocytoma. However, the scan is clear.
- In You Must Remember This, Nadia had received an MRI before she reached House to rule out a stroke or tumor.
- In Two Stories, Phillip Wright is given an MRI to try to find a foreign body in his lungs. In reality, a pea would most likely have shown up on an MRI, but in the show, the scan is clear and Phillip needs exploratory surgery to find the pea.
- In Recession Proof, House thinks Bert Eskey might have a viral infection in his brain and orders an MRI to look for it. The scan is clear, but the cold of the MRI room exacerbates his Muckle-Wells syndrome, leading House to eventually diagnose him with that condition.
- In Out of the Chute, House orders an MRI on Lane to look for abnormalities in his heart despite the steel reinforcing bars in his chest. Lane agrees to the procedure and his chest heats up while the doctors do the scan. However, they find no abnormalities in his heart.
- In Fall From Grace, House thought that Danny Jennings might have a tumor pressing against the nerves controlling sight and smell and ordered an MRI to look for it. There was no tumor on the scan, only dark spots on his parietal cortex. In addition, Danny suffered nausea during the procedure.
- In The Dig, when Nina didn't respond to treatment of Q fever, the team did an MRI to look for a brain issue that could be causing her symptoms. However, the scan was clean.
- In Last Temptation, Martha M. Masters thought that Kendall Pearson might have had a salmonella infection. When she found a painful spot on Kendall's arm, she got an MRI to confirm, but the spot turned out to be a deadly lymphosarcoma.
- In Changes, before Cyrus Harry was referred to House, he had an MRI of his spine to look for the cause of his lower limb paralysis.
- In The Fix, Foreman wanted to do an MRI of Wendy Lee to look for the cause of her seizure. House agreed, but the scan was clean.
- In Moving On, Foreman wanted to do an MRI on Afsoun Hamidi to look for signs of mental illness, but House refused.
Season 8[]
- In Transplant, after House finds a mass in the arm of the corpse of Stevie Weathers, he gets Chi Park to perform an MRI to confirm a rhabdomyosarcoma. However, the mass turned out to be coagulated plasma.
- In The Confession, Chase is providing palliative care to Bob Harris when he realizes the patient is confessing to things he couldn't possibly have done. Believing this might be due to a neurological problem, he performs an MRI and finds an aneurysm that leads them to the correct diagnosis.
- In Dead & Buried, House believes Iris is suffering from a HIV related condition and orders an MRI to look for the associated tumor. However, both the scan and the HIV test are negative.
- In Nobody's Fault, someone did an MRI on Bill Koppelman to rule out transverse myelitis before the case reached House.
- In Man of the House, House believes Joe Reese has multiple sclerosis and orders an MRI, but the scan is clean and also rules out the possibility of a tumor.
- In Love is Blind. House orders an MRI on the head of Will Westwood to look for a cause of his neurological symptoms. It finds a large dark area which House thought was a large clot, but later turned out to be mucormycosis.
- In Gut Check, Taub wanted to do an MRI on Bobby Hatcher to look for signs of brain damage, but House refused and instead ordered a psych consult.
- In Body and Soul, Adams thinks Lue might have Rasmussen's encephalitis. House allows an MRI, which is clear, which neither confirms nor rules out the diagnosis.
- In The C Word, Park suggests Emily Lawson might have Granulomatosis with polyangiitis and her mother, Dr. Elizabeth Lawson, orders an MRI because Emily can't have ionizing radiation because of her underlying genetic condition. The scan is negative, but Emily develops cyanosis during the procedure.
- In Post Mortem, Foreman has already done an MRI on Peter Treiber and had found an enlargement of the left ventricle of the heart.
- In Holding On, Adams thinks Derrick might have a migraine and does an MRI to confirm. However, the MRI shows that the blood vessels are not reactive, ruling out the diagnosis.
Magnetic resonance imaging at Wikipedia
This article uses text from Wikipedia licensed under the Creative Commons License.
Featured articles | ||
December 2014 | January 2015 | February 2015 |
Bile duct | Magnetic resonance imaging | Lockdown |
